Thursday, February 15, 2018

Planning Notes Updated: 2014 to 2018

This post is intended for people who are interested in the details of ecological restoration. It consists of five “cases” – with photos that exhibit problems or opportunities and comments on possible solutions.
The initial "Diagnoses" and "Prescriptions" were written in 2014.
(See http://vestalgrove.blogspot.com/2013/07/planning-notes-for-2014.html.)
In 2018 we comment on what we've actually done and learned since then.

First, a definition of a word used often below:
conservative – a species that is most common under long-evolved natural conditions – and rarely is found away from them. In fine prairie remnants, the conservatives are among the most common plants. In most “restored” or degraded prairies, they are rare or non-existent. A more detailed note on conservatives is at the end of this post.

Case 1

Diagnosis: Weeds here are under control. Yet few conservative species are established. Most of what’s here are short termers – species likely to mostly give way to others, for better or ill, before long. The early goldenrod, for example will likely be replaced excessively by big bluestem (present now in small numbers) if nothing is done but burn.

2014 Prescription: Broadcast seed of conservative species. Especially important are little bluestem and prairie dropseed – to head off the big bluestem. One place to sow seed of conservative species is the denser early goldenrod areas. These areas are ready.

2018 Comment: We do some of this, but not enough. We haven't sufficiently remembered this good advice at seed-gathering and seed-mixing time. We need to map opportunity areas more carefully this summer, plant some and hold back some as controls, and monitor the results. We are putting the needed mapping and seeds goals on our 2018 summer and fall priorities calendars.



Case 1A: close-up of a different part of area 1

Patches like the one shown above strike me as receptive to our most-prized conservative seed. There is currently little aggressive tall grass here. The commonest plants shown (early goldenrod, black-eyed Susan, fleabane) are among the quickest to move out of the way for quality species. Sow such classy species as cream false indigo, Leiberg’s panic grass, white and purple prairie clovers, prairie dropseed, alumroot, shooting star, prairie gentian, yellow stargrass, prairie cinquefoil, etc.

However, if you look closely at the photo above, you'll see quite a bit of gray dogwood and grape. Shrubs and vines may be holding this area back, especially if it doesn't get burned frequently. Woody plant shade may be progressively killing off most seedlings in most areas until the next burn - at which time the whole process starts over with more fleabane etc. Perhaps we may want to laboriously cut and herbicide those prairie-killing shrubs. Or perhaps you we to schedule this plot for annual burns until a more competitive herb flora wins out.

2018 Comment: We've watched this area and are more impressed than ever that "burn-off-and-regrow" shrub dynamics are ruling this area. Is that a good or bad? Certainly shrub dynamics are a component of the savanna dynamic. But are we missing half the species here that once made up that dynamic? Some say the principal shrubs were hazel and oak. Perhaps the grasses and forks that grew with them in this context aren't here now. And if so, is this now just a "retarded" weedy area that's stuck? We should install a transect of permanent plots and monitor plants here over time, to see if this area is changing, and how. Then we'll be better equipped to decide whether some change in protocols might improve it.

Case 1B: close-up area 2

This patch shows quite a bit of young big bluestem, dense patches of mountain mint, young ash trees, and dogwood shrubs. A patch like this may be less prime for conservative seed. Given how little seed we have of the high conservatives, we might want to seed this area sparingly. Perhaps it’s a place to add somewhat aggressive species like rattlesnake master, prairie dock, and compass plant – to increase the diversity of niches that the high conservatives will use to gradually become established from better areas nearby over the decades.

2018 Comment: Yeah, fine, 2014 commentator. But we really don't know the answer unless we monitor with permanent plots. Tom Vanderpoel assures us that prairie clover and shooting star will help break down dense big bluestem areas over time. Yes, we've seen that too. We've also seen areas where the bluestem resists other species for, it seems, decades. We would benefit from more permanent monitoring plots in seeded areas of dense big bluestem, mountain mint, tall goldenrod, and other resistant areas, to see what species might do best there.

Case 2

Here two high conservatives dominate (purple prairie clover and prairie dropseed).  Early goldenrod (which was dominant here years ago) has retreated to the frequency you might expect in stable, high-quality grassland. Although we see a little rattlesnake master, compass plant, and rough blazing star – the
overall diversity seems low. It might not work so well to sow the high conservatives of mid-summer here; the competition could be tough to overcome. Perhaps this is a place to sow spring species such as prairie betony, shooting star, and cream false indigo, which might then open up more niches.

On the other hand, this area is currently a great seed source for dropseed and prairie clover, so perhaps there’s no need to do much here in the short term. The best next step could be a variety of little inter-seeding experiments. First, find out which species will compete against these conservatives – before investing a lot of seed in an area, which might be slow to accept it.

2018 Comment: Ahh, yes. More experiments. Good ideas. So many plants and plots, and so little time.

Case 3
Two big questions here:
First, what do we do with the new planting shown below? It has good wildflower diversity but is weak on grass (and thus, unstable). As we study the vegetation that's emerging from the first seedings here, it’s hard to know whether this plot wants to be more mesic or wet-mesic overall. we’re thinking that we should especially sow dropseed and little bluestem in the drier parts – and switch grass and Dudley’s rush in the wetter parts. (At Somme, Dudley's rush seems especially common in many of the highest quality wet-mesic areas and is an especially "works-well-with-others" plant, that many conservative and endangered species thrive in when their seeds are broadcast.)
But, second, perhaps the biggest question here is what to do with all those trash trees in the background. This whole area was so dense with buckthorn that essentially no grasses or wildflowers survived. But in the foreground area, a grassy turf survived with only scattered invading trees, and when we cleared them, an on-the-way-to-quality seems to have come back. But under the large numbers of ash, cherry, elm, and box elder trees in the background, the quality is still poor. Strategically, it would take too big a big chunk of our volunteer time to cut and burn them. But there’s now no sensible community to try to restore on the former prairie or savanna land underneath them. So our short-term strategy has been to plant natural species that may keep out the invasives and then wait until we have more time or a better answer. If you look closely, you may be able to see brown leaves on some of the trees to the right. That’s where fire singed some of the branches. Maybe fire will do most of our work for us here, over time, while we invest our resources on other areas where the prescriptions are clearer.

2018 Comment: since 2014 we've cut a few big basswoods and box elders out of that wooded area and spread a bit more "Intermediate" light-level seed. Mostly we've ignored the area except for being happy that the burns have carried through at least some of it. Our impression is that vegetation diversity and conservatism is improving. But we have no monitoring transects here. It continues not to seem like a big priority, for now.

Case 4
            The above patch of scarlet oak savanna seemed to be getting increasing diversity and quality – until recently.
            Around the tree on the right, notice wild quinine, butterfly weed, ox-eye sunflower, big bluestem, wild bergamot, rattlesnake master, and others.
            Then woodland sunflower (Helianthus strumosus or perhaps hirsutus) started wiping out much of that diversity. Perhaps this is a temporary stage, and diversity will come back? Or perhaps this sunflower is helpfully erasing species that aren’t so well adapted here, which will then be replaced by better-adapted species, if we broadcast their seed.

2018 Comment: In many areas, depauperate patches of woodland sunflower are spreading. It seems worth our time to monitor these areas to get to understand them better – and experiment by inter-seeding likely associates, if we can identify good candidates. (Check out lists of associates. The old Swink and Wilhelm was little help, but the new "The Flora of the Chicago Region" by Wilhelm and Rericha seems to have a lot more to study.)

Case 5
Diagnosis: About half the trees in the center isolated grove shown above are dead. Some died from fire and others from Dutch elm or Emerald ash borer diseases. The few oaks are fine. Because we hadn’t had time to focus on it, we’ve left this dying grove to “nature.”  Of course, “nature” isn’t happening here, and the result is an increasingly unsustainable weedy and brushy mess. It will soon be another buckthorn monstrosity if we let current processes continue.
Possible Prescriptions
            We might plant some of our precious mixes of rare grasses and wildflowers around the edge. One mix is designed for the "Intermediate" semi-shade of the edge. A "Woods" mix might compete well in the darker shade of the interior). That could help keep the buckthorn at bay, but it could also be a waste of seed and effort. Throwing rare seed into nasty buckthorn re-sprouts is a recipe for failure. Also, the Intermediate species that would grow there in the short term would not be adapted to the less shady conditions that are coming – as these mostly non-oak trees continue to die from disease and fire. Why waste rare seed that would have more payback elsewhere?
            Perhaps we could broadcast the seed of some of the easier-to-get semi-shade herb species in the shadier, inner, non-buckthorn areas. We'd hope that those species would seal the wound and ward off the brush? Perhaps. Or we could plant natural shrub-copse species in hopes to build another native shrub island that we could experiment with (much appreciated by the significant bird species that nest at Somme).
            Or we could short-circuit the misery and cut the out-of-place trees this winter. That would seem easiest. We could then just plant the open savanna/prairie mix (as in the foreground here), which would then be easily sustainable with little added effort beyond regular burns. But we’re trying to restore the natural savanna here, and we already have more than enough of the “prairie” component.
            We could plant hazelnuts and bur oak acorns and protect them from voles, rabbits, deer and fire in the early years. Perhaps some of the box elders and basswoods can for the next 15 or 20 years provide the amount of shade that oak and hazel will someday provide, and the community can transition gradually from non-oak to oak. This challenging area still needs a lot of observation, experimentation, and thought.

2018 Comment: So here's what we've actually done. Nothing in the denser, interior parts. Discovered many possible components of a good shrub thicket around the edge (hazel, pussy willow, black haw, nanny berry, silky and gray dogwoods, bur and scarlet oak). We've cut back some of the dense buckthorn edge that was overwhelming these areas. We've caged one hazel from the deer. We cut one tall patch of buckthorn and planted plugs of two-year-old wild plum, ninebark, and indigo bush inside a large cage. In one wet edge, we cut the buckthorn and planted wet prairie seeds. But 90% of this mess is like it was in 2014. We progress. We learn. We hope.

Final 2018 Comment: This is how the Somme experiment works: We prioritize as best we can and keep trying to do what seems strategic. It's like that old juggler's trick of keeping a lot of plates spinning, and we run back and give a bit more attention to what seems to need it – except that, when we get some area or aspect right, it just keeps succeeding forever, as the world turns. And we stewards seem to be happier all the time as, more and more, rare bits of ecosystem thrive richly on their own. Year round, we walk through and notice new successes and opportunities. We smile inside and thank our lucky stars for the opportunity to do this wonderful work.

-            -            -            -            -            -            -            -            -            -            -

... finally as promised ...

a longer note on ecological conservatives

In many ways, the main and most challenging goal of ecosystem restoration is to restore and maintain plentiful conservatives. If such plants and animals are diverse and common, all the others will be intermixed with them, and we will have achieved ecosystem conservation. Monitoring and analyzing the results according to floristic and animal quality is an important part of any conservation project or program.

In the most commonly used Floristic Quality Assessment system, conservativeness is ranked on a scale of 0 to 10, with 10 being the highest. Examples of Chicago-region plants in the 0 range include ragweed, annual fleabane, and common milkweed. Typical alien weeds like dandelion would also be given a zero rating if these ratings weren’t reserved for native species.

Examples in the 9 and 10 range include prairie dropseed, white prairie clover, fringed gentian, prairie gentian, cream false indigo, prairie lily, Leiberg’s panic grass, prairie cinquefoil, prairie sundrops, heart-leaved Alexanders, and the prairie white-fringed orchid.

Conservative animals may or may not require conservative plants. But the ecosystem is less without them. Examples of conservative butterflies found by Ron Panzer to require conservative vegetation include the regal fritillary, Aphrodite, and the Edwards hairstreak. Birds of conservation concern may live for a time in large pastures of alien grasses. But they’ll live sustainably in large high-quality prairies.

Introductions to conservativeness and the Floristic Quality Index are at
http://www.conservationresearchinstitute.org/assets/illinoisfqa.pdf
and
https://willfreyman.org/assets/pdf/2015_Freyman_Masters_Packard_FQA.pdf
and
https://universalfqa.org

Note to readers: We always appreciate questions and comments. Thanks.

Saturday, February 10, 2018

Seeding the Snow

It surprises some people that we might seed the snow.
But it makes the seeds very happy.


As in nature, they don't function best sitting dry in bags all winter.
Wild seeds are adapted to being cold, and wet.
To get buried in the soil, they are adapted to the freeze thaw-cycle,
which churns the upper soil, and covers up the seeds.

We stewards are busy, and it's important to broadcast seed right.
But it's February. Spring is on the way.
Un-broadcast seeds are eager to get out.


Our mixes contain hundreds of species.
All different sizes and shapes.
Propagules for flowers of every color.
Grasses, sedges, ferns, lilies, orchids.


Do these seeds look to be scattered awful thin?
Yet this is precious rare stuff.
And every plant will be wide and tall in different ways when it grows.
We've tried different densities, and this seems about right.


Some seeds will be eaten by birds.
Although it will snow again tonight.
So these will be safe for now.

Some will not be quite right for this habitat.
So they may germinate and die.
Or the seedling may be eaten by a snail.
But many will thrive. We know that, from experience.

Keep in mind that these rare and uncommon plants
as they mature, will be from six inches to three feet wide
and from a few inches to many feet tall.
Scattered as the seeds are, this space will be full of life.


Here is the before.
Beautiful, but lonely.
We have cut out the buckthorn.
We have weeded and herbicided the invasives to prepare for this day.
We will cut more pole trees to "let there be more light" next summer.
We will pull noxious weeds for a year or two -
while this patch still needs intensive care.


But now it looks like this.
Formerly pristine snow trampled in concentric circles.
Temporarily foreign gritty-looking stuff de-purifyng the crystalline whiteness.
And yet, nature is returning.
Plants and animals will thrive in this nature on into the future.
The ecosystem is pleased.




Sunday, October 08, 2017

A Second Chance for the Fringed Gentian (Gentianopsis crinita)

There were none surviving in our area when we started learning to be forest preserve stewards in 1977. Early botanists Higley and Raddin considered fringed gentian (Gentianopsis crinita) to be "frequent or common, locally" in 1891. Herman Pepoon documented populations in the north suburbs in his 1927 flora, but he called it “doomed by its beauty,” noting that it was “rapidly vanishing before the onslaughts of the commercial flower gatherer.  Not one today where there were hundreds when the above was first written.”

As we worked to restore nature, we looked for all the missing plants that used to live here. We found seed sources nearby, for example along the railroads, which harbored a great many of the rarest plants, and we found most species, but we never found a fringed gentian.

In 1979, we gratefully harvested six gentian seed capsules from Markham Prairie with the approval of Dr. Robert F. Betz, its steward and our mentor. Actually, we asked Dr. Betz to “borrow” that seed.

We spread the seed in what looked like a good area of Miami Woods Prairie. This plant is a biennial. That is, in its first year it grows just a little "rosette" of leaves that lie flat on the ground - and saves energy and nutrients in its roots. Then in its second year, it puts up a flowering stalk and, if all goes well, makes a lot of seed and dies. Only the seeds live over that winter. And thus, at Miami Woods, the miracle occurred, and in 1981 one hundred and fifty seven gentian plants bloomed – a triumph!

Then tragedy – the deer quickly ate more than half of them. (In later years, I think we would have scattered the seeds around more - rather than putting them all in one patch.) But, somehow, the deer didn’t continue on to eat the other half. So we ended up with hundreds of capsules – enough to repay Markham and Dr. Betz and to spread the seed widely in three other prairies: Bunker Hill, Wayside, and Somme Prairie Grove.

In 1982 we noticed no gentians. Was that early success a fluke? But in 1983 we found them blooming in all four preserves. Small numbers only. But they offered hope.

I began to monitor the gentians annually, when I got a chance. The numbers below describe the beginnings of the gentian’s second chance – in the North Branch preserves.

Number of Fringed Gentians at Four Preserves


1981
1982
1983
1984
1985
1986
1987
1988
 Bunker Hill
0
-
3
-
-
0
109
0
Miami
157
-
30
3*
1
6
65
0
 Wayside
0
-
4
4*
-
1
3
0
 Somme
0
-
7
-
149
54
900
0
      0 = I checked and found no plants.
- = I didn’t have time to check carefully. I was busy.
      * = According to a note, all the plants in 1984 were “small and pathetic.”

In his 1910 wildflower book, Chester Reed wrote that this gentian “because of its exquisite beauty and comparative rarity, is one of the most highly prized of our wildflowers.” Then, after a few lines of poetry, he went on to write, “The Fringed Gentian is rather a fickle plant; we may find it in a certain locality one year and then search in vain for it for the next few years.”

Ahh, yes. This handsome character is unusual among the conservative prairie flora. It is a biennial. Most often when we find it, every plant nearby has deep perennial roots or fat tubers that tide plants over in times of drought or deer onslaughts.

Fringed gentian is a gambler. The seed lies in the soil until each smart little embryo somehow senses the time is right. How does it predict the rains? Or does it wait until nearby plants have been weakened by something? Or what is it that triggers the germination of these seeds?

In any case, unpredictably, our fringed beauty was now “off and running.” But did we have a problem - as a result of starting with just six capsules? How much genetic breadth was among them? Dr. Betz used to tell us how striking it was that this gentian came and went – often showing up in very different places from year to year. We had a start with one source. We should keep working to find other sources.

Fortunately, we learned from Barbara Turner that years ago some Long Grove folks had “rescued” fringed gentians when Chevy Chase Prairie in nearby Buffalo Grove was destroyed. It’s worth noting here the significance of those Long Grove folks. When Barbara Turner was a young woman, she took a course at the Morton Arboretum, where she met the great May Theilgaard Watts. Watts – like the visionary landscape architect Jens Jensen – had Danish heritage and brought to America the treasure of Scandinavian nature culture. Barbara often quoted Watts; when doing so she showed a reverence in her tone and expression. I would like to include in this post copies of two beautiful letters Watts wrote to Barbara (in the 1950s?). She gave me copies of those letters, but who knows where they are in all my piles of stuff. For now, it will have to suffice that, from memory, I can say that Watts visited the Long Grove woods and its people. She praised and encouraged those folks. That community in support of nature was still thriving in the mid 70s when Chevy Chase Prairie (said to be the finest black-soil surviving in Illinois) was intentionally bulldozed by its owner. Those Long Grove folks rescued many species from bulldozed piles of prairie turf, including gentians, and brought them to prairies they were restoring. Thus it came to pass that the great Barbara Turner (heroine of other stories that need to be told) gave a second source of local fringed gentian seeds to us. So now, the North Branch gentians are a mix of Markham and Chevy Chase genes.
This gentian was stepped on by some deer or person earlier in the year and is lying half on its side. But it has about 50 thriving flowers and seems well on its way to making about 30,000 seeds. If the deer don't eat it. Every year is a drama.

Over the decades, I stopped finding time to monitor gentians, but I'd check in on them occasionally at Somme Prairie Grove, where I was now steward. Somme's fringed gentians seemed to be entirely absent some years – and just a few in the others. So when Lisa Culp Musgrave started visiting Somme and becoming a fine photographer there, I asked her if she might like me to teach her how to be a steward for one of our most photogenic plants.

She hesitated – and then plunged in. Starting in 2008, she first made six deer-exclusion cages and placed them over six big and beautiful gentians, as I had suggested. (We noticed that the deer had already eaten many that year.) Too excited to stay away for long, Lisa returned soon to check her work.  She found that all six of her caged beauties had been cut down and killed by voles. But she had seen the vole-exclusion cages that I had been using to protect a related species (the prairie gentian, which we had even fewer of), and she started making many vole excluders to protect the smaller (but now even more precious) gentians that were still uncut and blooming hopefully. With the double caging, many happily set seed. That fall, Lisa and I triumphantly broadcast some of the matured embryos in places where the existing flora suggested they might do well. The results are apparent in the graph below:
This graph shows "The Lisa Bump." She took over care for this species in 2008.
A dedicated person can make a big difference (and enjoy life at the same time!).

Actually, truth to tell, Lisa did such a splendidly spectacular job on the gentians that I started feeling weird about it. We had so many other species that were so much rarer and needier. I feared I’d misled her.

When Lisa tells the story, she claims that I gave her a trivial exercise to see if she was any good. That’s not right, although I suppose it is true that I didn’t want to turn over my work on “super high priority” species to someone I hardly knew. In any case, now I had to convince her that she was carving out so much more time than I seemed to have – and was doing so much better a job – that she really, please, should do less gentian work and, pretty please, take over the federal endangered prairie white-fringed orchid. The great Lisa Culp Musgrave is now famous as an orchid steward; that Somme drama is described at:
http://vestalgrove.blogspot.com/2012/09/leave-nature-alone.html.

And her gradual moving on from the gentian provided another experiment. Could this formerly doomed beauty, with its numbers well bulked up, then make it on its own?
Deer have eaten almost all the flowers off this gentian. If it keeps up, such plants will die without setting seed.
Eriko Kojima caged a few last year and this. What would happen if we stopped?
I have no great confidence that this fickle species will be permanently part of the Somme ecosystem. It may or may not. At this point, our fringed gentians seem to do well some years in two very different situations. After we’ve cut the brush in a semi-wet area, now with very low competition, it can bloom by the hundreds, if some steward takes the trouble to harvest some seeds and broadcast them. But also in some years it does well in certain of our very highest quality areas, where you'd think competition would be the most challenging.

Could it be that, once we get some seeds waiting in the soil, this once common species will thrive in now-rare high-quality wet-ish prairies and open woods?

In most recent years, we haven’t found time to monitor them. Lisa's been busy. I've been busy. But other folks have pitched in from time to time. In 2011, we did monitor, and we found 194. In 2014 it was 845. Then this year, after no counts for two years, we found 415 in a dozen widely separated areas.

The clock is running, and it’s still early in the game. This population is only 34 years old.

It's been a pleasure. Bless them.


PS: If you’d like to read about these gentians in spectacularly more technical detail, a more detailed gentian post that covers additional questions is at Somme’s “less fun blog” – Strategies for Stewards: http://woodsandprairie.blogspot.com/2017/11/fringed-gentian-genetics-techniques-and.html.
